Alüminyum Bronz
MOSTON | ALUMINUM BRONZE | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Yield / MPa | Tensile / MPa | Elongation% | Hardness HB |
M11 | CuAl9 | 0.3 max. | 0.5 max. | 0.3 max. | 1.2 max. | 1.0 max. | 8.0- 10.5 | 0.2 max. | 0.5 max. | 88.0- 92.0 | 180 | 500 | 20 | 100 |
CC330G | 0.3 max. | 0.5 max. | 0.3 max. | 1.2 max. | 1.0 max. | 8.0- 10.5 | x | 0.5 max. | 88.0- 92.0 | 160 | 450 | 15 | 100 | |
C95200 | x | x | x | 2.5- 4.0 | x | 8.5- 9.5 | x | x | 86.0 min. | 179 | 469 | 20 | 125 | |
MOSTON | ALUMINUM BRONZE | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Yield / MPa | Tensile / MPa | Elongation% | Hardness HB |
M12 | CuAl10Fe2 | 0.2 max. | 0.5 max. | 0.1 max. | 1.5- 3.5 | 1.5 max. | 8.5- 10.5 | x | 1.0 max. | 83.0- 89.5 | 200 | 550 | 15 | 130 |
AB1 | 0.1 max | 0.5 max. | 0.03 max. | 1.5- 3.5 | 1.0 max. | 8.7- 10.5 | x | 1.0 max. | Rem. | 200- 270 | 560- 650 | 20- 30 | 120- 160 | |
CC331G | 0.2 max | 0.5 max. | 0.1 max. | 1.5- 3.5 | 1.5 max. | 8.5- 10.5 | x | 1.0 max. | 83.0- 89.5 | 200 | 550 | 18 | 130 | |
C95400 | x | x | x | 3.5 max. | 2.5 max. | 10.0- 11.5 | x | 0.5 max. | 83.0 min. | 220 | 586 | 10 | 170 | |
SAE 68 | x | x | x | 0.8- 1.5 | x | 9.0- 11.0 | x | x | Rem. | 179 | 483 | 25 | 125 | |
MOSTON | ALUMINUM BRONZE | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Yield / MPa | Tensile / MPa | Elongation% | Hardness HB |
M13 | CuAl10Ni3Fe2 | 0.2 max. | 0.5 max. | 0.1 max. | 1.0- 3.0 | 1.5- 4.0 | 8.5- 10.5 | x | 2.0 max. | 80.0- 86.0 | 220 | 550 | 20 | 120 |
CuAl9Ni | 0.2 max. | 0.5 max. | 0.1 max. | 1.0- 3.0 | 1.5- 4.0 | 8.5- 10.0 | x | 2.5 max. | 82 min. | 230 | 530 | 20 | 120 | |
CC332G | 0.2 max. | 0.5 max. | 0.1 max. | 1.0- 3.0 | 1.5- 4.0 | 8.5- 10.5 | x | 2.0 max. | 80.0- 86.0 | 220 | 550 | 20 | 120 | |
MOSTON | ALUMINUM BRONZE | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Yield / MPa | Tensile / MPa | Elongation% | Hardness HB |
M14 | CuAl10Fe5Ni5 | 0.1 max. | 0.5 max. | 0.03 max. | 4.0- 5.5 | 4.0- 6.0 | 8.5- 10.5 | x | 3.0 max. | 76.0- 83.0 | 280 | 650 | 13 | 150 |
CuAl10Ni | 0.1 max. | 0.5 max. | 0.03 max. | 3.5- 5.5 | 4.0- 6.5 | 8.5- 11.0 | x | 3.0 max. | 76 min. | 300 | 700 | 13 | 160 | |
AB2 | 0.1 max. | 0.5 max. | 0.03 max. | 4.0- 5.5 | 4.0- 5.5 | 8.8- 10.0 | x | 3.0 max. | Rem. | 250- 310 | 670- 730 | 13- 20 | 140- 180 | |
CC333G | 0.1 max. | 0.5 max. | 0.03 max. | 4.0- 5.5 | 4.0- 6.0 | 8.5- 10.5 | x | 3.0 max. | 76.0- 83.0 | 280 | 650 | 13 | 150 | |
C95500 | x | x | x | 3.0- 5.0 | 3.0- 5.5 | 10.0- 11.5 | x | 3.5 max. | 78.0 min. | 290 | 650 | 10 | 190 | |
C95800 | 0.1 max. | 0.5 max. | 0.03 max. | 3.5- 4.5 | 4.0- 5.0 | 8.5- 9.5 | x | 0.8- 1.5 | 79 min. | 262 | 620 | 18 | 159 | |
SAE 68 B | x | x | x | 1.0 min. | x | 10.0 min. | x | x | 89.0 min. | 186 | 550 | 20 | 140 | |
MOSTON | ALUMINUM BRONZE | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Yield / MPa | Tensile / MPa | Elongation% | Hardness HB |
M15 | CuAl11Fe6Ni6 | 0.2 max. | 0.5 max. | 0.05 max. | 4.0- 7.0 | 4.0- 7.5 | 10.0- 12.0 | x | 2.5 max. | 72.0- 78.0 | 380 | 750 | 5 | 185 |
CuAl11Ni | 0.2 max. | 0.5 max. | 0.05 max. | 4.0- 7.0 | 5.0- 7.5 | 9.0- 12.3 | x | 2.5 max. | 73.0 min. | 400 | 750 | 5 | 185 | |
CC334G | 0.2 max. | 0.5 max. | 0.05 max. | 4.0- 7.0 | 4.0- 7.5 | 10.0- 12.0 | x | 2.5 max. | 72.0- 78.0 | 380 | 750 | 5 | 185 | |
CW308G | 0.1 max. | 0.5 max. | 0.05 max. | 5.0- 7.0 | 5.0- 7.0 | 10.5- 12.5 | x | 1.5 max. | Rem. | 420 | 740 | 5 | 200 |
