Moston Metalurji Ltd. Şti
Özel Döküm Prinçleri
MOSTON | ÖZEL DÖKÜM PRİNÇLERİ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPa | Uzama % | Sertlik HB |
M17 | Cu55ZnMn | 0.2 max. | Rem. | 0.5 max. | 0.5- 1.5 | 1.0- 3.0 | x | x | 1.5- 3.5 | 55.0- 64.0 | 150 | 235 | 15 | 85 |
MOSTON | ÖZEL DÖKÜM PRİNÇLERİ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPa | Uzama % | Sertlik HB |
M18 | CuZn35Al1 | 1.0 max. | 35.0 min. | 0.5 max. | 0.5- 1.5 | 0.5- 1.5 | 1.0- 2.0 | x | 1.0- 2.0 | 58.0- 61.0 | 200 | 490 | 10 | 120 |
HTB1 | 1.0 max. | Rem. | 0.5 max. | 0.7- 2.0 | 1.0 max. | 0.5- 2.5 | 0.05 max. | 0.1- 3.0 | 57.0 min. | 210- 280 | 500- 600 | 20- 38 | 100- 150 | |
CC765S | 1.0 max. | Rem. | 0.5 max. | 0.5- 2.0 | 6.0 max. | 0.5- 2.5 | 0.03 max. | 0.5- 3.0 | 57.0- 65.0 | 200 | 500 | 18 | 120 | |
C86400 | 0.5- 1.5 | 34.0- 42.0 | 0.5- 1.5 | 0.4- 2.0 | 1.0 max. | 0.5- 1.5 | x | 0.1- 1.5 | 56.0- 62.0 | 138 | 413 | 20 | 105 | |
MOSTON | ÖZEL DÖKÜM PRİNÇLERİ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPa | Uzama % | Sertlik HB |
M19 | CuZn34Al2 | 0.3 max. | Rem. | 0.3 max. | 0.5- 2.5 | 3.0 max. | 1.0- 3.0 | x | 0.5- 4.0 | 55.0- 66.0 | 260 | 620 | 14 | 150 |
HTB2 | 0.5 max. | Rem. | 0.5 max. | 0.5- 2.5 | 2.0 max. | 5.0 max. | x | 3.0 max. | 58.0- 61.0 | 280 | 590 | 15 | 155 | |
CC764S | 0.3 max. | Rem. | 0.3 max. | 0.5- 2.5 | 3.0 max. | 1.0- 3.0 | 0.03 max. | 1.0- 4.0 | 55.0- 66.0 | 260 | 620 | 14 | 150 | |
C86200 | 0.2 max. | 22.0- 28.0 | 0.2 max. | 2.0- 4.0 | 1.0 max. | 3.0- 4.9 | x | 2.5- 5.0 | 60.0- 66.0 | 310 | 621 | 18 | 180 | |
SAE 430 A | 0.2 max. | 22.0- 28.0 | 0.2 max. | 2.0- 4.0 | 1.0 max. | 3.0- 4.9 | x | 2.5- 5.0 | 60.0- 66.0 | 310 | 621 | 18 | 180 | |
MOSTON | ÖZEL DÖKÜM PRİNÇLERİ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPa | Uzama % | Sertlik HB |
M20 | CuZn25Al5 | x | Rem. | x | 1.5- 4.0 | 3.0 max. | 3.0- 7.0 | x | 2.5- 5.0 | 60.0- 67.0 | 480 | 750 | 5 | 190 |
HTB3 | 0.2 max. | Rem. | 0.2 max. | 1.5- 3.25 | 1.0 max. | 3.0- 6.0 | x | 1.4- 4.0 | 55.0 min. | 400- 500 | 740- 930 | 13- 21 | 150- 230 | |
CC762S | 0.2 max. | Rem. | 0.2 max. | 1.5- 4.0 | 3.0 max. | 3.0- 7.0 | 0.03 max. | 2.5- 5.0 | 60.0- 67.0 | 480 | 750 | 5 | 190 | |
C86300 | 0.2 max. | 22.0- 28.0 | 0.2 max. | 2.0- 4.0 | 1.0 max. | 5.0- 7.5 | x | 2.5- 5.0 | 60.0- 66.0 | 414 | 621 | 12 | 225 | |
SAE 430 B | 0.2 max. | 22.0- 28.0 | 0.2 max. | 2.0- 4.0 | 1.0 max. | 5.0- 7.5 | x | 2.5- 5.0 | 60.0- 66.0 | 414 | 621 | 12 | 225 | |
MOSTON | ÖZEL DÖKÜM PRİNÇLERİ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPa | Uzama % | Sertlik HB |
M21 | CuZn37Al1 | 0.5 max. | Rem. | 0.5 max. | 0.5 max. | 2.0 max. | 0.3- 1.8 | x | 0.5 max. | 60.0- 64.0 | 170 | 450 | 25 | 105 |
CC766S | 0.5 max. | Rem. | 0.5 max. | 0.5 max. | 2.0 max. | 0.3- 1.8 | x | 0.5 max. | 60.0- 64.0 | 170 | 450 | 25 | 105 | |
C85800 | 1.5 max. | 31.0- 41.0 | 1.5 max. | 0.5 max. | 0.5 max. | 0.55 max. | x | 0.25 max. | 58.0 min. | 193 | 331 | 9 | 61 |
