Moston Metalurji Ltd. Şti
Yüksek Kurşunlu Kalay Bronz
| MOSTON | YÜKSEK KURŞUNLU KALAY BRONZ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPaa | Uzama % | Sertlik HB |
| M7 | CuSn5Pb9 | 4.2- 6.0 | 2.0 max. | 8.5- 10.0 | 0.15 max. | 2.0 max. | x | 0.05 max. | x | 80.0- 87.0 | 90 | 200 | 6 | 60 |
| LB4 | 4.0- 6.0 | 2.0 max. | 8.0- 10.0 | 0.25 max. | 2.0 max. | x | 0.1 max. | x | Rem. | 80- 110 | 220- 300 | 6- 13 | 60- 80 | |
| CC494K | 4.0- 6.0 | 2.0 max. | 8.0- 11.0 | 0.25 max. | 2.0 max. | x | 0.1 max. | x | 80.0- 87.0 | 90 | 200 | 6 | 60 | |
| C93500 | 4.3- 6.0 | 2.0 max. | 8.0- 10.0 | 0.2 max. | 1.0 max. | x | 0.05 max. | x | 83.0- 86.0 | 110 | 207 | 12 | 60 | |
| SAE 66 | 4.3- 6.0 | 2.0 max. | 8.0- 10.0 | 0.2 max. | 1.0 max. | x | 0.05 max. | x | 83.0- 86.0 | 83 | 193 | 15 | 60 | |
| MOSTON | YÜKSEK KURŞUNLU KALAY BRONZ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPaa | Uzama % | Sertlik HB |
| M8 | CuSn10Pb10 | 9.2- 11.0 | 1.0 max. | 9.0- 10.5 | 0.25 max. | 2.0 max. | x | 0.1 max. | x | 78.0- 82.0 | 110 | 220 | 8 | 70 |
| LB2 | 9.0- 11.0 | 1.0 max. | 8.5- 11.0 | 0.15 max. | 2.0 max. | x | 0.1 max. | x | Rem. | 150 | 290 | 15 | 85 | |
| CC495K | 9.0- 11.0 | 2.0 max. | 8.0- 11.0 | 0.25 max. | 2.0 max. | x | 0.1 max. | x | 78.0- 82.0 | 110 | 220 | 6 | 70 | |
| C93700 | 9.0- 11.0 | 0.8 max. | 8.0- 11.0 | 0.15 max. | 1.0 max. | x | 0.15 max. | x | 78.0- 82.0 | 135 | 240 | 20 | 60 | |
| SAE 64 | 9.0- 11.0 | 0.8 max. | 8.0- 11.0 | 0.7 max. | 0.5 max. | x | x | x | 78.0- 82.0 | 150 | 290 | 15 | 85 | |
| MOSTON | YÜKSEK KURŞUNLU KALAY BRONZ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPaa | Uzama % | Sertlik HB |
| M9 | CuPb15Sn | 8.0- 11.0 | 1.0 max. | 13.5- 16.5 | x | 2.0 max. | x | 0.1 max. | x | 74.0- 80.0 | 220- 300 | 130- 160 | 4- 10 | 70- 90 |
| LB1 | 8.0- 11.0 | 1.0 max. | 13.5- 16.5 | x | 2.0 max. | x | 0.1 max. | x | 74.0- 80.0 | 220- 300 | 130- 160 | 4- 10 | 70- 90 | |
| CC496K | 6.0- 8.0 | 2.0 max. | 13.0- 17.0 | 0.25 max. | 0.5- 2.0 | x | 0.1 max. | x | 74.0- 80.0 | 90 | 200 | 7 | 65 | |
| C93800 | 6.3- 7.5 | 0.8 max. | 13.0- 16.0 | 0.15 max. | 1.0 max. | x | 0.05 max. | x | 75.0- 79.0 | 110 | 200 | 16 | 55 | |
| SAE 67 | 6.3- 7.5 | 0.8 max. | 13.0- 16.0 | 0.15 max. | 1.0 max. | x | 0.05 max. | x | 75.0- 79.0 | 110 | 200 | 18 | 55 | |
| MOSTON | YÜKSEK KURŞUNLU KALAY BRONZ | Sn | Zn | Pb | Fe | Ni | Al | P | Mn | Cu | Akma/MPa | Çekme/MPaa | Uzama % | Sertlik HB |
| M10 | CuPb20Sn | 4.0- 6.0 | 1.0 max. | 19.0- 23.0 | 0.15 max. | 2.0 max. | x | 0.1 max. | x | Rem. | 80- 110 | 190- 270 | 7- 15 | 50- 70 |
| LB5 | 4.0- 6.0 | 1.0 max. | 19.0- 23.0 | 0.15 max. | 2.0 max. | x | 0.1 max. | x | Rem. | 80- 110 | 190- 270 | 7- 15 | 50- 70 | |
| CC497K | 4.0- 6.0 | 2.0 max. | 18.0- 23.0 | 0.25 max. | 0.5- 2.5 | x | 0.1 max. | x | 70.0- 78.0 | 80 | 170 | 6 | 50 | |
| C94100 | 4.5- 6.5 | 1.0 max. | 18.0- 22.0 | 0.25 max. | 1.0 max. | x | 0.05 max. | x | 72.0- 79.0 | 115 | 170 | 16 | 52 | |
| SAE 94 | 4.5- 6.5 | 1.0 max. | 18.0- 22.0 | 0.25 max. | 1.0 max. | x | 0.05 max. | x | 72.0- 79.0 | 115 | 170 | 16 | 52 |
